Welcome to ZHEJIANG MODENG LIGHTING TECHNOLOGY CO.,LTD.
description   description

285-9R Recessed with trim light

Back


PowerL*W*H(mm)Lumen/PowerItem No
Low1180*80*452000lm/20W285-9R.F120W
1470*80*452500lm/25W285-9R.F125W
2340*80*454000lm/40W285-9R.F140W
Medium1180*80*452800lm/28W285-9R.A128W
1470*80*453500lm/35W285-9R.A135W
2340*80*455600lm/56W285-9R.A156W


Material & technology


Light distribution:Direct Light

Light source:High brightness SMD LED, or T5 (G5)

Color rendering:CRI≥80, can customize CRI≥90

CCT:3000K, 4000K, 6500K, can customize 5000K

Driver:Equipped with high conversion rate driver, optional with 0-10V dimming, DALI dimming, SCR dimming

Lamp material:High grade anodizing aluminum (6063 Alloy), painted with White can customize other color

Diffuser:Opal prismatic diffuser with high transmittance and uniformity light

End caps material:ABS

IP:20

Connection:The luminaries can be connected with end cap in 180°, the connectors need to be ordered separately.

Installation:S-Suspended, C-Ceiling mounted,W-Wall mounded,R-Recessed without trim
