Welcome to ZHEJIANG MODENG LIGHTING TECHNOLOGY CO.,LTD.
description   description

903R Recessed with trim light

Back


PowerL*W*H(mm)Lumen/PowerItem No
Low1180*55*962000lm/20W903R.F120W
1470*55*962500lm/25W903R.F125W
2340*55*964000lm/40W903R.F140W
Medium1180*55*962800lm/28W903R.A128W
1470*55*963500lm/35W903R.A135W
2340*55*965600lm/56W903R.A156W
High1180*55*965320lm/38W903R.2A138W
1470*55*966580lm/47W903R.2A147W
2340*55*9610640lm/76W 903R.2A176W


Material & technology


Light distribution:Down& Side Light

Light source:High brightness SMD LED, or T5 (G5)

Color rendering:CRI≥80, can customize CRI≥90

CCT:3000K, 4000K, 6500K, can customize 5000K

Driver:Equipped with high conversion rate driver, optional with 0-10V dimming, DALI dimming, SCR dimming

Lamp material:High grade anodizing aluminum (6063 Alloy), painted with White, can customize other color

Diffuser:Opal prismatic diffuser with high transmittance and uniformity light                    End caps material:ABS

IP:20

Connection:Can make shadowless continuous lighting system

Installation:S-Suspended, C-Ceiling mounted, R-Recessed without trim
