205S Suspend light

Back


PowerL*W*H(mm)Lumen/PowerItem No
Low 1177*81*902000lm/20W205S.H120W
1467*81*902500lm/25W205S.H125W
2337*81*904000lm/40W205S.H140W
Medium1177*81*902800lm/28W205S.C128W
1467*81*903500lm/35W205S.C135W
2337*81*905600lm/56W205S.C156W
High
1177*81*905320lm/38W203S.2A138W
1467*81*906580lm/47W203S.2A147W
2337*81*9010640lm/76W203S.2A176W




PowerL*W*H(mm)Lumen/PowerItem No
Low1177*81*904000lm/40W205S.F120/H120W
1467*81*905000lm/50W205S.F125/H125W
2337*81*908000lm/80W205S.F140/H140W
Medium1177*81*905600lm/56W205S.A128/C128W
1467*81*907000lm/70W205S.A135/C135W
2337*81*9011200lm/112W205S.A156/C156W
High
1177*81*905320lm/38W205S.2A138/2C138W
1467*81*906580lm/47W205S.2A147/2C147W
2337*81*9010640lm/76W205S.2A176/2C176W



Material & technology


Light distribution:Direct/Indirect Light or Direct Light

Light source:High brightness SMD LED, or T5 (G5)

Color rendering:CRI≥80, can customize CRI≥90

CCT:3000K, 4000K, 6500K, can customize 5000K

Driver:Equipped with high conversion rate driver, optional with 0-10V dimming, DALI dimming, SCR dimming

Lamp material:High grade anodizing aluminum (6063 Alloy), painted with Glossy Silver, can customize other color

Diffuser:Opal prismatic diffuser with high transmittance and  uniformity light                  End caps material:ABS

IP:20

Connection:Can make shadowless continuous lighting system

Installation:S-Suspended, C-Ceiling mounted, or R-Recessed without trim
